To automatically start or stop a Lua script:
1) Choose Device Settings > Event Rules >
2) Select 'Start/stop Lua script' from the Action list.
3) In the Operation field, select 'Start script' or 'Stop script.'
4) In the Script field, select the script that you want it to be started or stopped when an event occurs.
Scripts must be pre-loaded.
5) To apply different arguments than the default, do the following. Note that the newly-added
arguments will override this script's default arguments.
a. Click Add Argument. a.
b. Type the key and value. b.
▪ ▪ To remove any existing argument, click
Switch Outlet Group
The "Switch outlet group" action is available only when your PRO4X is outlet-switching capable. This
action turns on, off or power cycles a specific outlet group.
▶
Operation:
1) Choose Device Settings > Event Rules >
2) Select 'Switch outlet group' from the Action list.
3) To specify the outlet group where this action will be applied, select it from the 'Group to switch' list.
4) In the Operation field, select an operation for the selected outlet group.
• • Turn on all outlets in group: Turns on the selected outlet group.
• • Turn off all outlets in group: Turns off the selected outlet group.
• • Cycle all outlets in group: Cycles power to the selected outlet group.
Switch Outlets
The "Switch outlets" action is available only when your PRO4X is outlet-switching capable. This action
turns on, off or power cycles a specific outlet.
▶
Operation:
1) Choose Device Settings > Event Rules >
2) Select 'Switch outlets' from the Action list.
3) In the Operation field, select an operation for the selected outlet(s).
• Turn outlet on: Turns on the selected outlet(s). •
• Turn outlet off: Turns off the selected outlet(s). •
• • Cycle outlet: Cycles power to the selected outlet(s).
.
adjacent to it.
.
.
