Number Description
The following information is listed.
1)
• •
Serial number
• •
Chain position, which involves the following information:
• •
Port <N>: <N> is the number of the sensor port where this sensor or actuator is
connected.
• • Chain Pos. <n>: <n> is the sensor or actuator's position in a sensor daisy chain.
• •
If this sensor or actuator is on a sensor package with multiple channels, its channel number
is indicated.
Depending on the sensor type, any of the following information is displayed:
• •
State of a state sensor: Normal, Alarmed, Open or Closed.
• •
State of an actuator: On or Off.
• •
Reading of a numeric sensor.
X, Y, and Z coordinates which you specify for this sensor or actuator.
▶
To switch on or off an actuator:
By default peripheral actuator control is disabled. You have to enable it in the web interface.
See:Peripherals (on page 168)
1) Select "Peripherals" in the Main Menu, and press
.
. Select an actuator to switch and press
