LEGRAND Server Technology PRO4X User Manual page 247

• •
Select the rule above which you want to insert a new rule. For example, to insert a rule between rules
#3 and #4, select #4.
• • Click Insert Above.
• •
Type a starting IP address in the Start IP field.
• •
Type an ending IP address in the End IP field.
• •
Select a role in the Role field. This rule applies to members of this role only.
• •
Select Accept or Deny in the Policy field. Refer to the above table for details.
The system automatically numbers the rule.
1) When finished, the rules are listed on this page.
• • You can select any existing rule and then click
2) Click Save. The rules are applied.
▶
To configure IPv6 access control rules:
1) On the same page, select the 'Enable role based access control for IPv6' checkbox to enable IPv6
access control rules.
2) Follow the same procedure as the above IPv4 rule setup to create IPv6 rules.
3) Make sure you click the Save button in the IPv6 section, or the changes made to IPv6 rules are not
saved.
Editing or Deleting Role Based Access Control Rules
You can modify existing rules to update their roles/IP addresses, or delete them when they are no
longer needed.
or to change its priority.
247
