To view detailed information or configure each alerted sensor, click each sensor's name to go to
individual sensor pages. See
▶
Summary in the section title:
Information in parentheses adjacent to the title is the total number of alerted sensors.
For example:
• •
1 Critical: 1 sensor enters the critical or alarmed state. 1 Warned: 1 'numeric' sensor enters the
warning state.
• • Numeric sensors enter warning or critical states, as their values enter the threshold ranges.
• • State sensors enter an alarmed state.
See Sensor/Actuator States
Numeric sensors:
• •
Numeric sensors:
• •
State sensors:
• •

Dashboard - Inlet History

• •
The Inlet History graph displays the history of the sensor values. Select a different data type by
clicking the selector
Individual Sensor/Actuator Pages
(on page 175) for more details.
Warning
Critical
Alarmed state
below the diagram.
(on page 179).
