Sensor type
unbalancedLineLineCurrent Unbalanced Line-Line current
unbalancedVoltage
unbalancedLineLineVoltage Unbalanced line-line voltage
crestFactor
phaseAngle
residualACCurrent
Commands for Inlet Pole Sensors
A sensor configuration command for inlet poles begins with sensor inletpole. This type of command is
available on a three-phase PDU only.
You can configure various inlet pole sensor threshold settings at a time by combining multiple
commands.
▶
Set the Upper Critical Threshold for an Inlet Pole:
config:# sensor inletpole <n> <p> <sensor type> upperCritical <option>
▶
Set the Upper Warning Threshold for an Inlet Pole:
config:# sensor inletpole <n> <p> <sensor type> upperWarning <option>
▶
Set the Lower Critical Threshold for an Inlet Pole:
config:# sensor inletpole <n> <p> <sensor type> lowerCritical <option>
▶
Set the Lower Warning Threshold for an Inlet Pole:
config:# sensor inletpole <n> <p> <sensor type> lowerWarning <option>
▶
Set the Inlet Pole's Deassertion Hysteresis:
config:# sensor inletpole <n> <p> <sensor type> hysteresis <hy_value>
Description
Unbalanced voltage
Crest Factor
Phase Angle
RCM AC current sensor - detects residual AC current only.
Available only on PDUs with RCM Type A
