Variables:
• •
<ETH> is one of the network interfaces: ETH1/ETH2, WIRELESS, or BRIDGE. Note that you must
choose/configure the bridge interface if your PRO4X is set to the bridging mode.
Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP
parameters of ETH1/ETH2 and WIRELESS interfaces do NOT function.
Interface Description
eth1 Determine the IPv4 address of the ETH1 interface (that is, wired
networking).
eth2 Determine the IPv4 address of the ETH2 interface (that is, wired
networking).
wireless Determine the IPv4 address of the WIRELESS interface (that is,
wireless networking).
bridge Determine the IPv4 address of the BRIDGE interface (that is, the
bridging mode).
• • <ip address> is the IP address being assigned to your PRO4X. Its format is "IP address/prefix". For
example, 192.168.84.99/24.
Setting the IPv4 Gateway
After selecting the static IP configuration mode, you can use this command to specify the gateway.
config:# network ipv4 interface eth1 gateway <ip
address>
Variables:
• • <ip address> is the IP address of the gateway. The value ranges from 0.0.0.0 to 255.255.255.255.
Interface Description
eth1 Determine the IPv4 address of the ETH1 interface (that is, wired
networking).
eth2 Determine the IPv4 address of the ETH2 interface (that is, wired
networking).
wireless Determine the IPv4 address of the WIRELESS interface (that is,
wireless networking).
420
