After configuring the destination and authentication settings, do either or both of the following:
• •
To perform the data push after the occurrence of a certain event, create the data push action and
assign it to an event rule.
• • To push the data at a regular interval, schedule the data push action.
▶
To configure data push settings:
1) Choose Device Settings > Data Push.
2) To specify a destination, click
3) Set up the URL field.
a. Select http or https. a.
b. Type the URL or host name in the accompanying text box. b.
4) If selecting https, a CA certificate is required for making the connection. Click Browse to install it.
Then you can:
• • Click Show to view the certificate's content.
• Click Remove to delete the installed certificate if it is inappropriate. •
5) If the destination server requires authentication, select the 'Use authentication' checkbox, and enter
the following data.
• • User name comprising up to 64 characters
• • Password comprising up to 128 characters
6) In the 'Entry type' field, determine the data that will be transmitted.
• • Asset management tag list: Transmit the information of the specified asset strip(s), including the
general status of the specified strip(s) and a list of asset tags. The asset tags list also includes the
tags on blade extension strips, if any.
• • Asset management tag log: Transmit the log of all asset strips, which is generated when there are
changes made to asset tags and asset strips, including asset tag connection or disconnection
events.
• • Sensor log: Transmit the record of all logged sensors, including their sensor readings and/or status.
Logged sensors refer to all internal and/or environmental sensors/actuators that you have selected
on the Data Logging page.
7) If 'Asset management tag list' is selected in the above step, specify the asset strip(s) whose
information to send. Depending on your PDU model, only one strip may be available.
• To specify the asset strip(s), select them one by one from the Available AMS Ports list. Or click •
Select All to add all.
• To remove the asset strip(s), click that asset strip's •
Deselect All to remove all.
8) Click Create.
9) Repeat the same steps for additional destinations. Up to 64 destinations are supported.
.
in the Selected AMS Ports field. Or click
