Expansion 1 device:
Position code for Expansion 1 is '01' so each port number is 5NN01 as shown below.
Protocols
HTTPS
HTTP
SSH
TELNET
SNMP
MODBUS
Examples:
• •
To access Expansion 1 via HTTPS, the IP address is:
https://192.168.84.77:50001/
• •
To access Expansion 1 via HTTP, the IP address is:
http://192.168.84.77:50101/
• •
To access Expansion 1 via SSH, the command is:
ssh -p 50201 192.168.84.77
▶
Expansion 2 device:
Position code for Expansion 2 is '02' so each port number is 5NN02 as shown below.
Protocols
HTTPS
HTTP
SSH
TELNET
SNMP
MODBUS
Examples:
• • To access Expansion 2 via HTTPS, the IP address is:
https://192.168.84.77:50002/
• •
To access Expansion 2 via HTTP, the IP address is:
232
Port numbers
50001
50101
50201
50301
50501
50601
Port numbers
50002
50102
50202
50302
50502
50602
