Managing networks and connections

Set PCAP (such as Wireshark) traces

The traffic captured by the Analyzer is also available in PCAP format.
A network protocol analyzer, such as Wireshark, can read files in this PCAP format. This powerful
feature allows you to diagnose network protocol issues with relative ease.
There are several PCAP files available to download. Each file contains a different set of captured
packets.
Option PCAP File
IP anaip.pcap
Ethernet anaeth.pcap
PPP anappp.pcap
Wi-Fi anawifi.pcap
Wireshark is free software. To download, go to
É
Web
1. Go to Management > Analyser > PCAP (e.g. Wireshark) traces.
2. Click the displayed links to download the desired PCAP-format file.
Following is an example of Analyzer traffic output viewed in Wireshark:
Digi TransPort® Routers User Guide
Contents
IP traffic captured from all enabled IP sources.
Ethernet traffic captured from all enabled Ethernet sources.
PPP traffic captured from all enabled PPP sources.
Wi-Fi traffic captured from the enabled Wi-Fi source.
http://www.wireshark.org.
Analyze data traffic
