Configuring legacy protocols
Reason Code
OOC
INV
NC
DER
NA
NP
RPE
ERR
ROO
RNA
ID
FNA
SA
If an unknown reason code is received, the text field is blank.
ICLR command: Invitation To CLR
The ICLR command invites the remote X.25 service to CLR the current X.25 session.
INT command: Send interrupt packet
INT causes PAD to transmit an interrupt packet. These packets flow outside normal buffering/flow
control constraints interrupt the current activity.
LOG command: Log off and disconnect
LOG terminates an X.25 session. It causes the PAD to clear any active X.25 calls, disconnect, and
return to AT command mode.
PAR? command: List local X.3 parameters
PAR? lists the local X.3 parameters for the current session.
PROF command: Load or save a PAD profile
The PROF command stores or retrieves a pre-defined set of X.3 PAD parameters, called a PAD profile.
The information is stored in system file called X3PROF. There are 4 pre-defined profiles, numbered 50,
51, 90, and 91. Additionally, you can create 4 user PAD profiles, numbered 1 to 4. Profile 50 is
automatically loaded when a PAD is first activated. To load one of the other pre-defined profiles, use
the PROF command, followed by the required profile number. For example:
PROF 90
To create a user PAD profile, use the SET command to configure the various PAD parameters to suit
your application, then use the PROF command in the format:
PROF &nn
Digi TransPort® Routers User Guide
Numeric Code
1
3
5
9
11
13
17
19
21
25
33
41
57
Configure X.25 parameters
Text
number busy
invalid facility requested
temporary network problem
number out of order
access to this number is barred
number not assigned
remote procedure error
local procedure error
cannot be routed as requested
reverse charging not allowed
incompatible destination
fast select not allowed
ship cannot be contacted
