Managing networks and connections
First Loc. IP / Last Loc. IP
For IPsec tunnels that have been negotiated using IKEv2, this is the range IP addresses available on
the local IP network.
AH
The AH algorithm in use, if any.
ESP Auth
The ESP authentication algorithm in use, if any.
ESP Enc
The ESP encryption algorithm in use, if any.
IPComp
The data compression algorithm in use, if any.
KBytes Delivered
The total amount of data that has been transferred (in both directions) over this IPsec tunnel.
KBytes Left
The amount of data left to be transferred over the IPsec tunnel before the data duration limit is
reached. The data duration is negotiated between the router and the remote device.
Time Left
The time left, in seconds, before the time duration limit is reached. The time duration is negotiated
between the router and the remote device.
Interface
The interface over which the IPsec tunnel operates.
Show status of IPsec peers
Go to Management > Connections> VPN > IPsec > IPsec Peers. This page displays the current
status of the IPsec peers. This is the list of remote devices that have successfully negotiated an IPsec
tunnel with the router.
Peer IP Address
The IP address of the remote device.
Our ID
The ID of the router.
