T r a n s P o r t
W R 1 1
®
Wireless Routers

Installation Guide

90001936_A
January 8, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TransPort WR11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digi TransPort WR11

Summary of Contents for Digi TransPort WR11

  • Page 1: Installation Guide

    T r a n s P o r t W R 1 1 ® Wireless Routers Installation Guide 90001936_A January 8, 2014...

  • Page 2: Product Disposal Instructions

    Digi International reserves the right to modify or revise all or part of this document, its contents, and any products described herein at any time without prior notification and shall not be responsible for any loss, cost or damage, including consequential damage, caused by reliance on these materials.
  • Page 3 However, cellular-based products contain radio devices which require specific consideration. Please take the time to read and understand the following guidance. Digi International assumes no liability for an end user’s failure to comply with these precautions.

  • Page 4: Table Of Contents

    Troubleshooting Resources for Digi TransPort WR11 ..............12 Unable to Open the TransPort WR11 Web Interface ............... 13 Unable to Log in to the Digi TransPort WR11 Web Interface ............13 Appendix A Digi TransPort WR11 Hardware Specifications �������������������������������������������� 14 Appendix B Digi TransPort WR11 Accessories ����������������������������������������������������������������...

  • Page 5: Introduction To The Digi Transport Wr11

    Digi TransPort ® WR11 Installation Guide Introduction to the Digi TransPort WR11 Digi TransPort WR11 is a full-featured, cellular router offering the flexibility to scale from basic connectivity applications to enterprise class routing and security solutions. With its high performance architecture, Digi TransPort WR11 is designed for Wide Area Network connectivity including 2.5G and 3G networks.

  • Page 6: Digi Transport Wr11 Hspa+ Model Specifications

    Digi TransPort ® WR11 Installation Guide Digi TransPort WR11 HSPA+ Model Specifications 1. LAN: This Ethernet port connects the device to a 10/100 base-T Local Area Network (LAN). The port is capable of auto-sensing for speed and wiring, so it can accept both straight-through or cross-over cable connections.

  • Page 7: Digi Transport Wr11 Configuration

    Digi TransPort ® WR11 Installation Guide Digi TransPort WR11 Configuration Once you have installed and powered up the device, you need to configure it to communicate with the LAN or WAN. You can configure the device either using the Command Line Interface (CLI) or the Web Interface. The recommended configuration option is the Web Interface, which you can access via a web browser such as Firefox, Internet Explorer or Chrome.
  • Page 8 CDMA module itself, not the Digi’s configuration file. Mobile account information is stored on the CDMA module. Therefore, you cannot remove provisioning information from the CDMA module by performing a factory reset on the TransPort WR11 device.
  • Page 9 Digi TransPort ® WR11 Installation Guide Verizon Provisioning For a Verizon device, press the Start button under CDMA Provisioning (Configuration - Networks > Interface > Mobile) leaving the fields blank as shown in the following image. Sprint Provisioning A Sprint device will automatically start the provisioning process when you power the device on. This process may take several minutes to complete.

  • Page 10: Digi Transport Wr11 Command Line Interface (Cli)

    For additional information on this feature, refer to Application Note AN07 available at www.digi.com/support. Digi TransPort WR11 Command Line Interface (CLI) The Command Line Interface (CLI) can be accessed via Telnet and SSH using the IP address of the device.
  • Page 11 Digi TransPort ® WR11 Installation Guide Notes: The IP address configuration takes effect immediately. When you enter the command ETH 0 IPADDR • XXX.XXX.XXX.XXX, any Telnet or SSH connection gets disconnected. You should be able to reconnect to the new IP address.

  • Page 12: Troubleshooting The Digi Transport Wr11 Configuration

    WR11 device. Troubleshooting Resources for Digi TransPort WR11 There are several resources available to you for support of your Digi product or resolving configuration difficulties at Digi’s Support site, http://www.digi.com/support/. Additional resources are as follows: 1. Digi’s Support knowledge base: http://www.digi.com/support/kbase/.

  • Page 13: Unable To Open The Transport Wr11 Web Interface

    • Use the Digi Device Discovery Tool. The IP address of the WR11 device may have been changed from its default of 192.168.1.1. The Device Discovery Tool can usually discover the device on a network, unless your system’s firewall is enabled.

  • Page 14: Appendix A Digi Transport Wr11 Hardware Specifications

    Digi TransPort ® WR11 Installation Guide Appendix A Digi TransPort WR11 Hardware Specifications Specifications Digi TransPort WR11 General Features: Dimensions 3.9” x 5.2” x 1.3” (L x W x H) (10 cm x 13.1 cm x 3.2 cm) Weight 0.85 lbs.

  • Page 15: Appendix B Digi Transport Wr11 Accessories

    Digi TransPort ® WR11 Installation Guide Appendix B Digi TransPort WR11 Accessories The following sections provide the list of Digi TransPort WR11 accessories with the corresponding part numbers. Digi TransPort WR11 AC Power Supplies AC Power Supplies Part Number 5V 3.0A 2.5mm Locking, U.S. Plug 76000934 5V 3.0A 2.5mm Locking, International Plug Kit...

  • Page 16: Appendix C Digi Transport Wr11 Certifications

    Appendix C Digi TransPort WR11 Certifications Digi TransPort WR11 complies with the requirements of the following International Electromagnetic Compatibility (EMC) standards. International EMC (Electromagnetic Emissions/Immunity/Safety) Standards Digi TransPort WR11 complies with the requirements of the following Emissions, Immunity and Safety standards. Emissions Immunity...
  • Page 17 © 2014 Digi International Inc. All rights reserved. Digi, Digi International, the Digi logo, a Digi International Company, the Digi web site, Digi Remote Manager, Digi TransPort, Digi TransPort WR, and Digi TransPort WR11 are trademarks or registered trademarks of Digi International Inc.
