Configuring network interfaces
Keep Security Associations (SAs) when this PSTN interface is disconnected
When enabled, causes the router to maintain (such as not flush) the SA when the interface
becomes disconnected. The normal behavior is to remove the SAs when the interface becomes
disconnected.
Use interface x,y for the source IP address of IPsec packets
If it is required to use another interface (such as not the interface currently being configured)
as the source address for IPsec packets, this may be achieved by selecting the desired
interface from the drop-down list and typing the desired interface instance number into the
adjacent text box.
Enable the firewall on this interface
When enabled, applies the firewall rules to traffic using this interface.
3. Click Apply.
Command line
Command Instance
ppp n
ppp n
ppp n
ppp n
ppp n
ppp n
ppp n
ppp n
ppp n
ppp n
Digi TransPort® Routers User Guide
Parameter
name
phonenum
ph2
ph3
ph4
prefix
username
password
IPaddr
IPaddr
Configure DialServ interfaces
Equivalent web
Values parameter
Up to 25 Description
characters
up to 25 digits Dial out using numbers
" Dial out using numbers
" Dial out using numbers
" Dial out using numbers
0-9999999999 Prefix
Up to 60 Username
characters
Up to 40 Password
characters
0.0.0.0 Allow the remote device
to assign a local IP
address to this router
Valid IP address Try to negotiate a.b.c.d
a.b.c.d as the local IP address
for this router
(in conjunction with l_
addr)
