Note Use only one of the power connectors. Never apply power to both the MAIN and AUX connectors
at the same time.
The following image shows the pins and the corresponding numbers:
For more information on wiring and other details, see the 4-pin DC Power Cord User Guide, Digi part
number 90001246.
Digi TransPort® Routers User Guide
Pin Description
Pin 1 GROUND
Pin 2 INPUT
Pin 3 Input/ Output
Pin 4 Power
