USB on-the-go full-speed (OTG_FS)
Bit 8 OUTPKTERR: OUT packet error
Bits 7:6 Reserved, must be kept at reset value.
Bit 5 STSPHSRX: Status phase received for control write
Bit 4 OTEPDIS: OUT token received when endpoint disabled
Bit 3 STUP: SETUP phase done
Bit 2 Reserved, must be kept at reset value.
Bit 1 EPDISD: Endpoint disabled interrupt
Bit 0 XFRC: Transfer completed interrupt
OTG_FS device IN endpoint 0 transfer size register (OTG_FS_DIEPTSIZ0)
Address offset: 0x910
Reset value: 0x0000 0000
The application must modify this register before enabling endpoint 0. Once endpoint 0 is
enabled using the endpoint enable bit in the device control endpoint 0 control registers
(EPENA in OTG_FS_DIEPCTL0), the core modifies this register. The application can only
read this register once the core has cleared the Endpoint enable bit.
Nonzero endpoints use the registers for endpoints 1–3.
31 30 29 28 27 26 25 24 23 22 21
Reserved
1038/1378
This interrupt is asserted when the core detects an overflow or a CRC error for an OUT
packet. This interrupt is valid only when thresholding is enabled.
This interrupt is generated only after the core has transferred all the data that the host has
sent during the data phase of a control write transfer, to the system memory buffer. The
interrupt indicates to the application that the host has switched from data phase to the status
phase of a control write transfer. The application can use this interrupt to ACK or STALL the
status phase, after it has decoded the data phase.
Applies only to control OUT endpoints.
Indicates that an OUT token was received when the endpoint was not yet enabled. This
interrupt is asserted on the endpoint for which the OUT token was received.
Applies to control OUT endpoint only.
Indicates that the SETUP phase for the control endpoint is complete and no more back-to-
back SETUP packets were received for the current control transfer. On this interrupt, the
application can decode the received SETUP data packet.
This bit indicates that the endpoint is disabled per the application's request.
This field indicates that the programmed transfer is complete on the AHB as well as on the
USB, for this endpoint.
20
19
PKTCNT
rw
rw
18 17 16 15 14 13 12 11 10
Reserved
RM0033 Rev 8
9
8
7
6
5
4
3
XFRSIZ
rw rw rw rw rw rw rw
RM0033
2
1
0
