If you have any doubt about what switch to use, please contact your local distributor. They will help you select an
appropriate switch.
dot2 Wings
You can connect wings to your dot2 console or to dot2 onPC. The wings are assigned to a specific device. If this
device is lost on the network then the wing loose it's functionality and waits to be assigned to a different device.
There are two types of wings: the dot2 Fader wing (F-wing) and the dot2 Button wing (B-wing). Each gives you more
physical executors and an extra screen.
Since the wings are connected directly to a specific device you'll need to open the setup menu on the device you
want to connect a wing. In the Setup menu you'll find a button called dot2 Wings , tap this.
This gives you the Wings view. Here you can tap one of the free slots (yellow bar on the left side) of the same type as
your wing. There are only five slots for each device. Depending on your devices you might only have a few free slots.
Slots that are occupied by the console have a red bar on the left side - they are called "fixed, internally". Slots that
are currently occupied by an external wing will have a green bar in the left side.
When you tap a free slot you'll see the available wings in your network. If you don't see any wings here, then you
need to check you network and the connections - also make sure everything is powered on.
When you see a wing on the left side of the screen, then you can tap it. The wing you have selected will now flash
all the keys. This is so you can identify the select wing in a multi wings setup. When the correct wing is flashing,
then you can tap the Assign Selected button.
Now you have assigned and connected a wing and you can exit the menu.
dot2 consoles, dot2 onPC and dot2 3D visualizer
Everything, except wings, are connected to a
separate sessions running in your network.
The session system allows for a greater flexibility with regards of backup and redundancy.
Press Setup and then the Sessions button. This gives you the
parts the top part shows you if your console or onPC is currently in a network session or not.
If the button on the right side says Start a new or join an existing session , then you can press it to see the 4
different sessions. If there are some devices using one of the sessions then the session button will have the session
name and the button will say Join Session . If there isn't any session running then you can choose one of the
session and begin a new session. Now you can add more devices in your session.
If the button in the top part says Stop/Leave session , then the console is already connected to a session. and you
can add more devices to your session.
The lower part of the Network Setup view shows the devices in your session. They are separated into each type of
device. If you have devices in your network and they are in your session, then they have a green background color.
The device you are currently looking at will have a brighter green background color. If you are missing a device that
previously have been in your session, then it gets a red background color. You can see the IPv6 address, name and
© 2016 MA Lighting Technology Gm bH | Dachdeck erstr. 16 | D-97297 W aldbüttelbrunn | Germ any
Phone +49 5251 688865-27 | support (at) m a-dot2.com | www.m alighting.com
d o t 2 U s e r Ma n u a l
session . Wings are connected to a specific device. There can be 4
Network Setup view. This view is separated into two
