10. Ethernet 1+2 11. USB 2.0 12. USB 3.0 13. DisplayPort 1-4 Turn on the grandMA3 onPC command wing XT 1. Unpack the device. 2. Remove the packaging and cushioning material. 3. Place the device indoors on a stable surface.
Page 3
9. Press the power key on the front panel. The device starts booting. Turn off the grandMA3 onPC command wing XT Important: Do not press the power key to turn off the device. Only if a hard shutdown is necessary, press and hold the power key for more than 3 seconds.
6. If necessary, tap F8 to choose Boot device and select boot from USB. 7. Follow the onscreen instructions during the update process. To learn more about the update process, read the Update grandMA3 onPC windows hardware topic in the online user manual. Important: To configure the device, or to update or downdate the installed software, use a grandMA3 console or your PC or laptop with the grandMA3 onPC software installed.
Page 5
XT + grandMA3 processing unit M/L/XL Important: Independent of the devices connected to the grandMA3 onPC software, the number of parameters can only reach a maximum of 4 096. For more information see: Expand the Amount of Parameters topic.
