(sender-table-0)# set source-interface-name NQM_WAN
name of network interface to send packets from
Note: If you want to output packets to the WAN interface, simply set NQM_WAN as
the source interface name; otherwise, set the interface name to a specific interface
name listed in the network interface table.
(sender-table-0)# exit
2. Configure the "responder termination" side:
a. Bind a WAN interface to the NQM service:
(config-system) bind GigabitEthernet 0/0 nqm
Note: The chosen WAN interface should be the interface on which the NQM packets
are planned to flow bi-directionally and binding is necessary to create the
corresponding static NAT rules. If the NQM session is planned to flow within the LAN
then no binding is needed and this step can be skipped.
b. Configure a row in the Responder table:
(config-system)# nqm responder-table 0
(responder-table-0)# set responder-name
vmain_office_voip_responder_1
this line
(responder-table-0)# set local-port 3900
port number at responder termination
(responder-table-0)# exit ; activates the probe line
Note: Ensure that the local-port value is the same as the target-port value set for the
corresponding sender termination.
(responder-table-0)# set source-interface-name NQM_WAN
name of network interface to send packets from
Notes:
•
If you want to listen to the WAN interface, simply set NQM_WAN as the source
interface name; otherwise, set the interface name to a specific interface name
listed in the network interface table.
•
Ensure that the network interface the responder termination is listening upon is in-
sync with the target-ip value set for the corresponding sender termination.
(responder-table-0)# exit ; activates the responder line
