AudioCodes Mediant 800B MSBR User Manual page 989

Mediant 800B MSBR
Parameter
Web: Authentication Quality of
Protection
CLI: auth-qop
[AuthQOP]
Web: SBC User Registration
Time
CLI: sbc-usr-rgstr-time
[SBCUserRegistrationTime]
Web: SBC Proxy Registration
Time
CLI: sbc-prxy-rgstr-time
[SBCProxyRegistrationTime]
CLI: config-voip>sbc general-
setting sbc-rand-expire
[SBCRandomizeExpires]
Version 6.8
Proxy-Authenticate header as the authentication challenge
response.
Defines the authentication and integrity level of quality of
protection (QoP) for digest authentication offered to the client.
When the device challenges a SIP request (e.g., INVITE), it
sends a SIP 401 response with the Proxy-Authenticate header or
WWW-Authenticate header containing the 'qop' parameter. The
QoP offered in the 401 response can be 'auth', 'auth-int', both
'auth' and 'auth-int', or the 'qop' parameter can be omitted from
the 401 response. In response to the 401, the client needs to
send the device another INVITE with the MD5 hash of the INVITE
message and indicate the selected auth type.

[0] 0 = The device sends 'qop=auth' in the SIP response,
requesting authentication (i.e., validates user by checking user
name and password). This option does not authenticate the
message body (i.e., SDP).

[1] 1 = The device sends 'qop=auth-int' in the SIP response,
indicating required authentication and authentication with
integrity (e.g., checksum). This option restricts the client to
authenticating the entire SIP message, including the body, if
present.

[2] 2 = (Default) The device sends 'qop=auth, auth-int' in the
SIP response, indicating either authentication or integrity. This
enables the client to choose 'auth' or 'auth-int'. If the client
chooses 'auth-int', then the body is included in the
authentication. If the client chooses 'auth', then the body is not
authenticated.

[3] 3 = No 'qop' parameter is offered in the SIP 401 challenge
message.
Global parameter that defines the duration (in seconds) of the
periodic registrations that occur between the user and the device
(the device responds with this value to the user). You can also
configure this functionality per specific calls, using IP Profiles
(IpProfile_SBCUserRegistrationTime). For a detailed description
of this parameter and for configuring this functionality in the IP
Profile table, see ''Configuring IP Profiles'' on page 314.
Note: If this functionality is configured for a specific IP Profile, the
settings of this global parameter is ignored for calls associated
with the IP Profile.
Defines the duration (in seconds) for which the user is registered
in the proxy database (after the device forwards the REGISTER
message). This value is sent in the Expires header. When set to
0, the device sends the Expires header's value as received from
the user to the proxy.
The valid range is 0 to 2,000,000 seconds. The default is 0.
Defines a value (in seconds) that is used to calculate a new value
for the expiry time in the Expires header of SIP 200 OK
responses for user registration and subscription requests from
users.
The expiry time value appears in the Expires header in
REGISTER and SUBSCRIBE SIP messages. When the device
receives such a request from a user, it forwards it to the proxy or
registrar server. Upon a successful registration or subscription,
989
67. Configuration Parameters Reference
Description
Mediant 800B MSBR
