When an emergency call is answered:

Provide a VRS message to the destination.

After finishing the VRS message, start monitor operation which pre-programmed in Program

20-46-10. Also by pressing
monitor terminal is not idle status, an emergency call destination cannot start monitor and hear
no tone.
If a Watch or Warning message is sent to the destination and all VSR channels are busy, a

tone is played instead of displaying the VRS message.
If the VRS message is not recorded, a tone is played.

Barge-in is not allowed to outside call while monitoring.

A VRS message can be played from the extension's speaker only when the extension is

idle. But if a Watch or Warning message is requested while a normal page is being used,
normal paging stops and the Watch or Warning message is sent.
If a warning tone is provided instead of the VRS message, paging information is displayed

as a blank to the paging group terminal LCD.
If a Watch or Warning message happens during normal paging, normal paging stops and

the Watch or Warning message is sent.
A Warning message has a higher priority than a Watch message when both occur at same

time.
Activating or stopping sensor operations need to be set according to sensor specifications.

If an outgoing call restriction is set in a system, the number for the emergency call needs to

be pre-registered in the restriction allow table.
Auto outgoing call via leased line cannot go through when all trunks are busy.

When an emergency call destination is not answered, the system repeats the emergency

call the number of times specified in Program 20-46-08.
For Answer detection of Analog Trunks;

In case of answer supervision, when answer supervision is received, the system recognizes

the called party has answered.
In case of no answer supervision, after the inter digit timer has expired, the DTMF receiver

waits for the
During remote monitoring, the outside lines cannot be disconnected until the timer in

Program 20-21-05 expires.
For the Warning message:

Watch mode operation uses the order set in internal paging.

The VRS message can be edited using Service code Program 11-10-20.

The maximum length of a recorded message is two minutes.

Security

key from outside, it is possible to enable a two-way path. If the
key to be pressed. Then the system recognizes the called party has answered.

