VII. SERVICE MODE

A. Outline
The copier's service mode consists of three levels, each using its own screen: Initial screen,
Level 1/Level 2 item Screen, and Level 3 item screen.
User screen
( )(2,8)( )
Initial screen
Select an item.
Level 1/Level 2
item screen
Select a Level 1 item at the top of the screen.
Select a Level 2 item from the list.
Level 3 item
screen
Previous/Next page
COPYRIGHT © 1999 CANON INC.
Reset key
Reset key
From Level 1/
Level 2 item screen
Level 3 item
screen
Previous/Next page
Figure 13-701 Organization of Screens
