CHAPTER 8 FIXING SYSTEM
II.

FIXING DRIVE SYSTEM

A. Controlling the Speed of the Fixing Roller
The copier controls its fixing at one of two speeds to ensure good fixing performance for all
types of transfer media (plain paper, transparency).
The fixing motor starts to rotate when the drive signal (FXMON) goes '1', and its speed is
switched based on the combination of the states of the speed switch signals (FXMSP0, FXMSP1).
Related Error Code
E014
This code is indicated if the speed of rotation of the fixing motor deviates from a specific value and the
motor clock signal (FXMLK) goes '0'.
To prevent deformation otherwise caused by pressure, the fixing roller is rotated for about 0.6
sec at low speed (75 mm/sec) at intervals of 30 min after it has stopped rotating (in standby state).
Mode
Plain mode* (fixing on plain paper)
Initial multiple rotation, thick paper *
(106 to 209 g), transparency mode
8-4
COPYRIGHT © 1999 CANON INC.
Speed switch signal
FXMSP0
FXMSP1
1
0
Table 8-201
CANON CLC1120/1130/1150 REV.0 MAR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
Fixing speed
200mm/sec
1
75mm/sec
1
*Both first and second sides.
