Canon CLC 1120 Service Manual page 830

Level 3
B-HP Use it to rotate the attraction/transfer locking cam
motor, thereby moving the cam to the home position
(HP).
Using the Item
1) Select the item (to highlight), and press the OK
key.
2) The attraction/transfer locking cam will stop at
HP.
B-ATT-TR Use it to rotate the attraction/transfer locking cam
motor, thereby moving the cam to the point of
attraction/transfer.
Using the Item
1) Select the item (to highlight), and press the OK
key.
2) The cam will move to the point of attraction/
transfer, and will stop automatically.
B-TR Use it to rotate the attraction/transfer locking cam
motor, thereby moving the cam to the point of
transfer.
Using the Item
1) Select the item (to highlight), and press the OK
key.
2) The cam will move to the point of transfer, and
will stop automatically.
B-CLN Use it to rotate the attraction/transfer locking cam
motor, thereby moving the cam to the transfer drum
cleaning position.
Using the Item
1) Select the item (to highlight), and press the OK
key.
2) The cam will move to the transfer drum cleaning
position, and will stop automatically.
SENS-ADJ
Checks sensor-related operations.
Level 3
CLN-OFST Use it to execute temperature correction for the pre-
cleaning paper sensor (PS72).
Using the Item
1) Select the item (to highlight), and press the OK
key.
2) The operation will stop automatically.
· The screen (COPIER>ADJUST>SENS-ADJ) will
show the readings. Be sure to record them on the
service label.
COPYRIGHT © 1999 CANON INC.
Description
Description
CANON CLC1120/1130/1150 REV.0 MAR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 13 TROUBLESHOOTING
COPIER>FUNCTION
Remarks
Remarks
Execute this item when you
have replaced the pre-
cleaning paper sensor (PS72)
or removed it for cleaning.
13-303
