B. Sequence of Operations (jam detection)
A4/LTR, 1 Copy, Full-Color, Direct, Cassette 1
Photosensitive drum revolution
Transfer drum revolution
Side A sensor (PS2)
Side B sensor (PS3)
Laser
Registration sensor (PS70)
Transfer blade
Post-transfer paper sensor (PS6)
Pre-cleaning paper sensor (PS71)
Pre-transfer paper sensor (PS5)
Separation sensor (PS7)
Internal delivery sensor (PS12)
External delivery sensor (PS31)
COPYRIGHT © 1999 CANON INC.
DSRDY ended
DSRDY INTR
1
1
M
Transfer B M
Figure 7-602
CANON CLC1120/1130/1150 REV.0 MAR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 7 PICK-UP / FEEDING SYSTEM
COPY
2 3 4 5
2 3 4
C K
Y
Transfer B K
Transfer B C Transfer B Y
Delay jam check (normal if copy paper is present)
Stationery jam check (normal if copy paper is absent)
LSTR
6 7 8
5 6 7 8
STBY
7-47
