III. DUPLEXING UNIT (CLC1150 ONLY)
A. Outline

1. Basic Construction

Item
Duplexing tray capacity
Fixing motor (M5)
Delivery paper deflecting plate
solenoid (SL10)
Duplexing motor (M14)
Delivery vertical path clutch (CL19)
Duplexing feed clutch (CL14)
Stopper plate solenoid (SL12)
Duplexing paper feed roller
solenoid (SL13)
Stacking guide plate solenoid (SL15)
Paper jogging motor (PM14)
Re-pickup motor (PM13)
Re-pickup clutch (CL15)
Related error code
COPYRIGHT © 1999 CANON INC.
50 sheets (of 105 g/m
Drives the delivery system.
Used to switch the paper path (external delivery and
delivery vertical path)
DC motor; used to drive the delivery vertical path/
duplexing unit system.
Turns on/off the delivery vertical path roller 2/3.
Turns on/off the duplexing paper feed roller.
Drives the stopper plate.
Releases the duplexing paper feed roller.
Drives the stacking guide plate.
Drives the paper jogging guide.
Stepping motor used to drive the re-pickup system.
Turns on/off the duplexing separation roller and duplexing
feed roller.
E017
E051
Table 7-301
CANON CLC1120/1130/1150 REV.0 MAR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 7 PICK-UP / FEEDING SYSTEM
Description
2
paper)
Error in the duplexing motor.
Error in the paper jogging motor.
7-21
