D. Sequence of Operations (registration/attraction)
Cassette 1, A4, 2 Copies, Continuous, Full Color, Direct
Photosensitive
drum revolution
Transfer drum revolution
Side A sensor (PS2)
Side B sensor (PS3)
Laser
Registration sensor (PS70)
Registration roller releasing
solenoid (SL5)
Registration roller clutch
(CL9)
Attraction roller solenoid
(SL6)
Attraction brush
(high-voltage output)
Transfer blade
(high-voltage output)
Separation
charging assembly
Internal/external
static eliminator
Attraction/transfer locking
cam HP sensor (PS8)
Attraction/transfer locking
cam motor (PM7)
Brush/blade position
COPYRIGHT © 1999 CANON INC.
Copy Start key ON (2nd)
DSRDY INTR
1
1
M
M
M
Attraction/transfer
Figure 7-404
CANON CLC1120/1130/1150 REV.0 MAR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 7 PICK-UP / FEEDING SYSTEM
COPY
2 3 4
2 3 4
C Y
Y K
C
K
M C C K K
Y Y
Transfer
LSTR
5 6 7 8
5 6 7 8
Cleaning
STBY
7-33
