Canon CLC 1120 Service Manual page 91

Outputs from the DC Driver PCB (13/15)
(CLC1150 only)
Upper fixing cleaning
belt solenoid
Lower fixing cleaning
belt solenoid
Separation push-up
solenoid
Separation claw
solenoid
Registration roller
releasing solenoid
Attraction roller
solenoid
Pickup roller 1
solenoid
Pickup roller 2
solenoid
COPYRIGHT © 1999 CANON INC.
J501
-1
-2
SL1
J502
-1
-2
SL2
Transfer driver
PCB
+24V
J582 J322
-2 -A2
-A1
SL3 -1
Registration
path driver
PCB
+24V
J557 J312
-2
-B12
SL4 -1 -B13
+24V
J556
-2 -A1
-1 -A2
SL5
+24V
J551
-2 -A5
SL6 -1 -A6
Pickup driver
PCB
+24V
J347
J626
-15
-2
-16
DSL8 -1
+24V
J653 J348
-2 -15
-16
DSL9 -1
Figure 2-332
CANON CLC1120/1130/1150 REV.0 MAR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 2 BASIC OPERATION
DC driver PCB
+24V
J500 J1004
-A8
-A7
-A6
-A5
J321 J1014
-B1 -B10
SSPUPSL
J311 J1013
-B7 -B11
SCDSL
-B13 -B5
RGRLSL
-A17
-A1
GGUIDSL
J341 J1017
-A11 -A8
PUPD1SL
J344 J1018
-11
-A6
PUPD2SL
When '0', SL1 turns on.
UWEBSL
+24V
When '0', SL2 turns on.
LWEBSL
When '1', SL3 turns on.
When '1', SL4 turns on.
When '1', SL5 turns on.
When '1', SL6 turns on.
When '1', DSL8 turns on.
When '1', DSL9 turns on.
2-43
