Switches

See 90° Left Switches on page 172
ings.
NOTE: The switches draw an additional 15 W of power per vehicle (puck) when the vehicle
is moving at maximum acceleration or velocity (see
Ethernet
Connector
Power
Connector
Straight Section
RS-422
Connector
Figure 4-58: MagneMover LITE RS-422 Switch Electrical Connections
Table 4-18: MagneMover LITE RS-422 Switch Electrical Connections
Label
CM1
CM2
CM3
CM4
P1
LAN
MagneMover LITE User Manual
and
Bottom View (Left Switch Shown)
Description
RS-422 communication
RS-422 communication
RS-422 communication
RS-422 communication
+36V DC ±10%, 1.5 A typical, 5.0 A max
Ethernet – 10/100/1000 Base-Tx
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Specifications and Site Requirements
90° Right Switches on page 175
Table
Curve Section
RS-422 Connector
M8 Nano-Mizer, 4-Pin, Plug
M8 Nano-Mizer, 4-Pin, Plug
M8 Nano-Mizer, 4-Pin, Plug
M8 Nano-Mizer, 4-Pin, Plug
Mini-Conn-X, 4-Pin, Plug
RJ45, Socket, IP-67
Electrical Specifications
for mechanical draw-
4-9).
Curve Section
RS-422
Connector
Straight Section
RS-422
Connector
Connector Type
213
