V-brace Kits

Description
V-Shaped Rail Alignment Key Kit
Includes two 200-2002-00 keys &
four M6 x 12 mm screws
V-Shaped Rail Alignment Key Kit
Includes two 200-2002-01 keys &
four M6 x 12 mm screws
Switch Alignment Key Kit
Includes one 200-2078-00 key &
two M6 x 12 mm screws
Switch Alignment Key Kit
Includes one 200-2078-01 key &
two M6 x 12 mm screws
High Payload Switch Alignment
Key Kit
Includes one 200-2450-00 key &
two M6 x 12 mm screws
MagneMover LITE User Manual
Figure 4-32: Standard V-braces
Table 4-3: V-brace Kit Configurations
V-brace Materials
6061-T6 Aluminum, Hard-
coat Anodized per
MIL-A-8625-F, Type III,
Class 1, Non-dyed.
303 Stainless Steel,
passivate
6061-T6 Aluminum, Hard-
coat Anodized per
MIL-A-8625-F, Type III,
Class 1, Non-dyed.
303 Stainless Steel,
passivate
6061-T6 Aluminum, Hard-
coat Anodized per
MIL-A-8625-F, Type III,
Class 1, Non-dyed.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Specifications and Site Requirements
Mechanical Specifications
200-2002-xx
200-2078-xx
200-2450-xx
Use
G4 motors with aluminum
rails.
G4 motors with stainless
steel rails
Merge end of G4 standard
switch (short flipper) with
aluminum rails
Merge end of G4 standard
switch (short flipper) with
stainless steel rails
Merge end of G4 high
payload switch (long flip-
per) with aluminum rails
Catalog #
700-1416-00
700-1417-00
700-1418-00
700-1419-00
MMI-ML-K
VHPS-0
