Dual Array (Tandem) Wheeled Puck

Tandem wheeled pucks consist of two independent 2-wheel bogies (pucks) that are connected
to a mounting plate by pivots. Each bogie has its own magnet array as shown in
These tandem wheeled pucks are typically used in MagneMover LITE transport systems
where the material being moved weighs up to 10 kg. See
Mechanical Drawing, on page 186
Linkage Plate
Puck Body
Suspension
Wheels
Lateral Guide
Wheels
Magnet Array
For proper operation, the payload on the puck must fit within the payload envelope that is
shown in Figure
lope specification that is shown, refer to
Solution Consultant or TechConnect
[5.12]
130
Figure 3-36: Dual Array (Tandem) Wheeled Puck Payload Envelope
For proper operation, the payload on the puck and the velocity of the puck must fit within the
curve that is shown in
MagneMover LITE User Manual
for details.
Figure 3-35: Dual Array (Tandem) Wheeled Puck
3-36. If the payload is within the weight specification but outside the enve-
℠
(rockwellautomation.custhelp.com).
[2.62]
66.6
[1.44]
36.5
Figure 3-37.
