250 mm Motor
1000 mm Motor
125 mm R 90° Curve Motor
Left or Right Switch
*
2. Locate the motor or switch so that the protruding boss on the standard motor mount is
keyed into the beam and aligned to the T-nut. Install an M8 x 20 mm bolt and M8 split
lock washer as shown in
3. Using the Motor Alignment Fixture, adjust the position of the motor or switch along
the beam so it is properly centered on the beam as shown in
that the fixture is fully seated in the slot in the beam. For switches, also adjust the posi-
tion of the switch on the motor mount to make sure that the third face is properly posi-
tioned. Tighten the M8 bolt to 26 N•m [230 in•lb] with a 13 mm Hex socket to secure
the motor mount to the beam.
4. Continue to install motors and switches as described in
verify the position of the motor as described in
MagneMover LITE User Manual
Table 5-2: Motor Mount Reference
Motor Type
Make sure that the beam is oriented so that all internal fastening hardware is on the bot-
tom of the beam.
Figure 5-10
Motor Alignment Fixture
Figure 5-11: Positioning Motors and Switches
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Transport System Installation
Motor Mount
Qty
1 Center of beam
2 250 mm from each end of beam
1 Center of beam
1 Center of beam
and finger tighten.
Step
Step 3.
Installation
Location
*
Figure 5-11. Make sure
2, at every third motor
