4. Position the support post base 38 mm [1.50 in] from the end of the connector plate on
the post mount as shown in
with a 6 mm Hex wrench.
MagneMover LITE User Manual
Figure
Figure 5-30: Precision Rail Support Post to Post Mount Spacing
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
5-30. Tighten the M8 screws to 26 N•m [230 in•lb]
38.0
[1.5]
Installation
Option Installation
283
