Motor Mounting Using Custom Brackets - Rockwell Automation MagneMotion MagneMover LITE Original Instructions Manual

Design Guidelines
Transport System Design
• When attaching mounting brackets to the motors and securing the brackets to the track
as shown in
motor connections. This mounting method provides easy adjustment of the motor
position once the motor is installed.
MM LITE 1000 mm Motor
Mounting Bracket
Track
118
Figure 3-45, make sure that the brackets are located to allow access to all
Hardware
Figure 3-45: Motor Mounting Using Custom Brackets
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Motor Mounting Bracket
M6 Mounting Hardware
MagneMotion
