Precision Rail Single Array Vehicle

700-1525-00
[3.46]
88.0
[1.54]
39.0
[0.683]
17.35
[0.906]
23.00
[0.906]
23.00
[1.024]
26.00
Weight: 0.8 kg [1.6 lb]
Figure 4-42: Precision Rail Single Array Vehicle Mechanical Drawing
NOTICE
Exposed Materials
• 6061-T6 AL, Anodized per MIL-A8625-F, Type II, Class 2, Black.
• Stainless Steel.
• 316L/316L #2 Stainless Steel.
• 440C Stainless Steel.
• UHMW Polyethylene.
• Nitrile.
• Plastic.
• Mobilgear
MagneMover LITE User Manual
C
L
[1.54]
LOCKING HELICOIL INSERTS
39.0
[3.807]
96.70
The bearings on the precision rail vehicles must always be
lubricated with a thin coating of oil to provide proper opera-
tion and environmental protection.
™
600 XP Oil.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Specifications and Site Requirements
DIRECTION OF MOTION
[4.553]
115.64
[1.201]
30.51
[1.937]
49.21
All Dimensions in Millimeters [Inches]
Mechanical Specifications
[0.803]
20.40
