Installation Overview - Magnemotion Supplied Mounting - Rockwell Automation MagneMotion MagneMover LITE Original Instructions Manual

10. Create the Node Controller Configuration File (see
11. Power up the system and check all operating features, safety features, and connections
(see System Check-out on page
page 310).
Installation Overview – MagneMotion Supplied Mounting
The following sequence provides an overview of the installation of the MagneMover LITE
transport system using the MM LITE
and motor mounts.
NOTICE
1. Assemble a complete section of the system stand, including the stand and beam (see
Assembling Beams on page 247
2. Adjust the feet on the stand section to make sure that it is flat and level (see
the MagneMover LITE on page
3. Secure the stand section to the floor or other equipment as required (see
Transport System on page
4. Attach cable chase cover brackets to curve and switch motor mounts (see
Cable Chase Cover Brackets on page
5. Attach the motor mounts to all motors and switches (see
Motors and Switches on page
6. Install the motors and switches, make sure that the motors and guide rails are collinear
to each other and the tops of all motors are coplanar to each other and tighten the
V-braces (see
and Switches on page
NOTE: If railless motors are being used, make sure that the motor bodies are collin-
7. Install the power supplies, node controllers, network switches, and cables (see
ing Electronics on page
MagneMover LITE User Manual
309) and install the software (see
™
Make sure that the stand system where the MagneMover
LITE motors are mounted is properly grounded to safety
ground (earth).
251).
252).
255).
Mounting Motors and Switches on page
258, and Verify Motor and Switch Installation on page
ear to each other.
If motors are installed in a wash-down environment, it must not exceed IP65.
Make sure that there is sufficient space around the motor mounting surface
for all connectors and for the bend radius of all cables.
263).
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Software on page
transport system components, including stand, beam,
and Installing System Legs on page
254).
256,
Installation
Transport System Installation
307).
System Power-up on
248).
Leveling
Securing the
Installing
Installing Motor Mounts on
Align and Secure Motors
262).
Install-
243
