Maintenance
Preventive Maintenance
Procedure
1. Stop all motion on the section of the MagneMover LITE transport system where the
vehicle is located.
2. Locate the lubricator under the precision rail vehicle.
The lubricators can be mounted between the concentric bearings or the eccentric bear-
ings as shown in
both locations on the same vehicle. The felt end of the lubricator is always pointed
inwards toward the rail with the refill access portal at the opposite end of the reservoir.
See Figure 7-8
Lubricator
Concentric
Bearings
Felt Applicator
3. Insert the tip of the oil filled syringe into the refill hole on the lubricator.
NOTE: On single array vehicles, if the lubricator is located between the concentric
364
Figure 7-7. Some systems can have lubricators that are mounted in
for an illustration of the lubricator housing.
Felt Applicator
Figure 7-7: Precision Rail Vehicle Lubricator Location
Figure 7-8: Precision Rail Vehicle Lubricator (Front and Rear)
bearings (on the magnet array side of the vehicle), use the lubrication portal
that is shown in Figure 7-9
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Lubricator
Felt Applicator
to access the oil refill hole on the lubricator.
Eccentric
Bearings
Oil Refill
