Installation

Unpacking and Inspection

Unpacking and Inspection
The MagneMover LITE transport system components are shipped in separate packages. Open
each package carefully following the steps that are provided in
page 239; inspect and verify the contents against the shipping documents. Report any damage
immediately to the shipper and to MagneMotion
One set of shipping documents is attached to the outside of the main shipping crate for easy
access.
NOTE: The number and contents of the shipping packages depends on the items that are pur-
chased and their configuration (that is, shipped as components or shipped as a sys-
tem). See the shipping documents for the exact contents. The checklist in
is provided for reference only.
Table 5-1: MagneMover LITE Component Packing Checklist Reference
Package
MagneMover LITE Motors
MagneMover LITE Stands
MagneMover LITE Pucks
or magnet arrays
Node Controllers
Power Supplies
Installation Kit
Precision Rail Option
Precision Locator Option
238
MagneMover LITE linear synchronous motors.
Modular aluminum stand system configured for the motors.
Includes beam sections, motor mounts, and cable chase covers.
MagneMover LITE pucks/magnet arrays for use as the LSM sec-
ondary to move material on the transport system.
MagneMotion node controllers for managing the nodes in the
transport system.
Power supplies to provide logic and propulsion power to the Mag-
neMover LITE motors.
• Miscellaneous hardware.
• Cables.
• User manuals, drawings, and so on.
• Straight and curve rails.
• Post and post/mount assemblies.
• Spine plates.
• Vehicles.
• Precision locator.
• Locator stand.
• Adjustable motor mounts.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Unpacking and Moving on
®
.
Contents
Table 5-1
