Installation
Check-out and Power-up

System Power-up

After the MagneMover LITE transport system has been installed, all connections must be
checked. Then, an initial power-up must be performed before proceeding any further with the
installation process. This section describes the procedure for the initial installation check-out.
1. Make sure that all installation procedures that are previously described in this chapter
have been completed.
2. Make sure that the system is properly grounded.
3. Connect the MagneMover LITE transport system to the electrical services for the
facility. Make sure that the power remains off.
4. Perform a Ground Continuity check from the surfaces of the MagneMover LITE trans-
port system to a known good ground.
5. Apply power to the MagneMover LITE transport system.
310
PINCH/CRUSH HAZARD
Moving mechanisms have no obstruction sensors.
Do not operate the MagneMover LITE components without
barriers in place or personal injury could result in the squeez-
ing or compression of fingers or other body parts between
moving mechanisms.
AUTOMATIC MOTION HAZARD
Whenever power is applied, the possibility of automatic
movement of the vehicles (pucks) on a MagneMover LITE
transport system exists, which could result in personal injury.
SHOCK HAZARD
110V AC @ 8.5 A (220V AC @ 5 A).
Make sure that the AC circuit suppling power to the
power supplies for the motors is properly sized and
properly protected.
NOTICE Use a current-limited power supply to verify the
polarity of all connections before using the system
power supply.
