Startup Indicators - Rockwell Automation MagneMotion MagneMover LITE Original Instructions Manual

The indicators on the components of the MagneMover LITE transport system light as
shown in
Node Controller, NC-S
Node Controller, NC-E
Node Controller, NC-12
MM LITE Power Supply
6. If power-up was successful, the MagneMover LITE transport system is ready to accept
commands. If however, the power-up sequence was unsuccessful, see
on page
7. Create the Node Controller Configuration File for the transport system (see
Configuration on page 307
MMI-UM008).
8. Set the IP address for each node controller. See the Node Controller Interface User
Manual, MMI-UM001, for more details. If EtherNet/IP is being used, see the Magne-
Mover LITE Configurator User Manual, MMI-UM008, for additional configuration
information.
9. Configure one node controller as the HLC. See the Node Controller Interface User
Manual, MMI-UM001, for more details.
10. Upload the configuration, image, and type files to each node controller (see the Node
Controller Interface User Manual, MMI-UM001).
MagneMover LITE User Manual
AUTOMATIC MOTION HAZARD
The host controller initiates all motion control to the
MM LITE transport system. It is the responsibility of
the user to initiate a safe startup of all MM LITE
components.
Do not attempt to operate the MagneMover LITE
transport system until all setup procedures that are
described in this chapter have been completed.
Table 5-5.
Table 5-5: Startup Indicators
Component
371.
and the MagneMover LITE Configurator User Manual,
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Check-out and Power-up
Indicator
Power
(Power)
Power
Logic Enabled
Propulsion Enabled
Installation
Status
On (green)
On (blue)
On (green)
On (green)
On (green)
Troubleshooting
Software
311
