Precision Rail Curve, 180°, No Joint, Spine Plate, Mechanical Drawing - Rockwell Automation MagneMotion MagneMover LITE Original Instructions Manual

700-1622-06
114.2°
141.5°
Figure 4-49: Precision Rail Curve, 180°, No Joint, Spine Plate, Mechanical Drawing
MagneMover LITE User Manual
110.30
100.42
2X 95.00
76.40
R169.88
9.58
0
128.5°
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Specifications and Site Requirements
Mechanical Specifications
[0.25]
6.35
All Dimensions in Millimeters
197
