• When supplying power directly to the NC LITE, plug the power supply into
the power distribution from the main power disconnect for the facility. Then,
connect the cable from the NC LITE power supply to the NC LITE.
• Make sure that the NC LITE node controllers are mounted to grounded sur-
faces.
5. Connect power to each SYNC IT
• Plug the power supply into the power distribution from the main power discon-
nect for the facility. Then, connect the cable from the SYNC IT power supply
to the SYNC IT.
• Make sure that the SYNC IT controllers are mounted to grounded surfaces.
6. Connect AC power to each power supply for the motors.
• Connect the power cable from the power distribution on the main power dis-
connect for the facility to the power connector on the MM LITE power supply
as shown in
engages the power supply.
• Connect the power cable from the power distribution on the main power dis-
connect for the facility to the power connector on any additional power sup-
plies as specified by the manufacturer.

E-stop Circuit

The MagneMover LITE transport system can use digital I/O, provided through a node control-
ler, for monitoring and control of local options such as an E-stop. The optional E-stop circuit
is the responsibility of the user and requires a user-supplied E-stop button and DC power sup-
ply for the digital input. See the Node Controller Hardware User Manual, MMI-UM013, for
the digital I/O equivalent circuits. See the MagneMover LITE Configurator User Manual,
MMI-UM008, for information on configuring an E-stop.

Interlock Circuit

The MagneMover LITE transport system can use digital I/O, provided through a node control-
ler, for monitoring and control of local options such as interlocks. The optional interlock cir-
cuit is the responsibility of the user and requires a user-supplied +3...24V DC power supply
for the digital input. See the Node Controller Hardware User Manual, MMI-UM013, for the
digital I/O equivalent circuits. See the MagneMover LITE Configurator User Manual,
MMI-UM008, for information on configuring an interlock.
MagneMover LITE User Manual
™
controller:
Figure 4-60. Make sure that the lock on the cable connector
SHOCK HAZARD
The E-stop is not the same as an EMO (Emergency Off),
which removes power to the MagneMover LITE transport
system.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Installation
Facilities Connections
305
