Motor Mounting Methods

The following motor mounting guidelines are provided when designing a guideway.
• When attaching directly to the track or mounting plate as shown in
sure that clearance holes for all motor connections are provided. This mounting
method does not provide for any adjustment of the motor position once the motor is
installed unless adjustment features are provided in the mounting plate.
MM LITE 1000 mm Motor
MagneMover LITE User Manual
Figure 3-44: Motor Mounting to Flat Surface
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Design Guidelines
Transport System Design
Figure
Mounting Plate
Clearance Holes for
Motor Connections
M6 Mounting Hardware
3-44, make
