Required Tools and Equipment
• 700-1585-00 – Kit, ML Puck Wear Surfaces Replacement. Contains:
• 700-1587-00 – Kit, ML Puck Wear Surfaces Replacement, Complete (2X).
• Screw, Shoulder, Skt, Ø5 mm X 6 mm Long, M4 Thread (2X).
• Washer, Spring, Belleville, for 0.190" /M5, Acetal (2X).
• Replace Glide Puck Wear Surfaces
• Linkage Plate Assembly, Plastic, ML High Payload Puck, Tandem.
• Fixture, Tandem Linkage Plate Installation.
• Torque wrench.
• Loctite 243, Thread locker Anaerobic Adhesive, Blue.
• Isopropyl Alcohol.

Disassemble Tandem Puck Assembly

1. Remove the tandem glide puck from the MagneMover LITE transport system (see
Replace Pucks on page
2. Place the tandem puck linkage plate installation fixture (shown in
flat surface.
3. Place the tandem puck in the fixture as shown in
Tandem Puck
Installation
4. Remove the two screws and washers that secure the linkage plate to the two pucks as
shown in
MagneMover LITE User Manual
399).
Fixture
Figure 7-20: Place Tandem Glide Puck in Fixture
Figure 7-21 and dispose of properly.
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
procedure on page 402.
Figure 7-20.
Maintenance
Repair
Figure 7-20) on a
