Transport System Software Overview

Several software applications are used to configure, test, and administer a MagneMover LITE
transport system as shown in
tation on page 33
Host Controller
(EtherNet/IP or TCP/IP)
NC Web Interface
(TCP/IP)
NC Console Interface
(RS-232)
Virtual Scope Utility
(MMI_Virtual_Scope.exe)
NCHost TCP Interface Utility
(NCHost.exe)
demo_script.txt
MagneMotion Configurator
(MMConfigTool.exe)
track_layout.ndx
Ethernet Motor Comm Tool
(mmi_commtool.exe)
Figure 1-8: Simplified View of Transport System Software Organization

Utilities

• NC Web Interface – A web-based software application that is supplied by MagneMo-
tion and resident on the node controllers, for administration of the transport system
components.
MagneMover LITE User Manual
Figure 1-8 and described after the figure. See
for the reference manuals for these applications.
System Control
Node Controller
Administration
Node Controller
Administration
Performance
Monitoring
System Testing
track_file.mmtrk
node_configuration.xml
MICS_motor_data.xml
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Transport System Software Overview
Related Documen-
Node Controller
Node Controller Software Image
(controller_image)
Motor ERF Image Files
(motor_image.erf)
Motor Type Files
(motor_type.xml)
Magnet Array Type Files
(magnet_array_type.xml)
Node Controller Configuration File
(node_configuration.xml)
MagneMotion Info and Config Service
(MICS_motor_data.xml)
Restricted Parameters File
(restricted parameters.xml)
Motors
NC File Retrieval Tool
(NC_File_Retriever.exe)
Introduction
