6.
Insert the fuse module into the PEM make sure that it is oriented correctly.
7.
Close the power entry module and make sure that the cover snaps into place.
8.
Return the power supply to normal operation.
DC Fuses
1.
Turn off power to the MM LITE Power Supply and unplug the power cable.
2.
Remove the fuse by turning the fuse holder (shown in
3.
Remove the old fuse and install a new fuse.
250V AC, 10 A ceramic slow blow fuses
4.
Insert the fuse holder and turn the fuse holder clockwise until fully seated.
5.
Return the power supply to normal operation.
MagneMover LITE User Manual
NOTICE
Never force the Fuse Module when inserting. Make
sure that it is not at an angle before inserting and
slides straight in.
Fuse Type
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Maintenance
Figure
7-32) counter-clockwise.
Fuse Location
Single fuse per fuse holder.
Repair
427
