Design Guidelines
Transport System Design

Dual Array Vehicle

Vehicles with two magnet arrays, as shown in
systems when the material being moved weighs up to 5 kg [11.0 lb]. See
sion Rail Dual Array Vehicle Mechanical Drawing, on page 192
Vehicle Body
Precision
Bearings
Magnet
Array
For proper operation, the payload on the vehicle and the velocity of the vehicle must fit within
the curve that is shown in
6
5
4
3
2
1
0
0
Figure 3-42: Dual Array Precision Rail Vehicle Payload vs. Velocity
114
Figure 3-41: Dual Array Precision Rail Vehicle
Figure 3-40.
Dual Array Precision Rail Vehicle Max Velocity
0.5
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Figure 3-41, are typically used in precision rail
1 1.5
Velocity (m/s)
Figure 4-43, Preci-
for details.
DIRECTION OF TRAVEL
2 2.5
