Design Guidelines
Transport System Options

Precision Rail Lubrication

The rails and bearings are an open system that requires continuous lubrication. To avoid
breakdown of the lubrication, the precision rails must always have a thin film of oil across the
entire rail system and the bearings in the vehicles. This coating provides both lubrication and
environmental protection. The interval to resupply the lubrication depends on the distance
traveled, load on the vehicles, and environmental factors. There are several different methods
for lubricating the rails as described here. Use 68 viscosity mineral oil, such as Kluber 4
UH1-68N, to lubricate the bearing rails.
Manually Lubricate the Rails
Lubricate the rails manually when needed (see
page
362).
Use Vehicle Mounted Lubricators
Install lubricators on the vehicles to provide continuous lubrication (see
Lubricators on Precision Rail Vehicles on page
the rail.
Figure 3-58
requires a second vehicle with a lubricator for the other side of the rail.
Lubricator
132
shows the single array vehicle with one lubricator. This configuration
Figure 3-58: Lubricator on Single Array Vehicle
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Manually Lubricate the Precision Rails on
433). Lubricators are required for each side of
Install/Replace the
MagneMotion
