Design Guidelines

Puck Limits

Puck Limits

Cantilevered Payloads

The following guidelines are provided when designing offset material carriers that are
mounted on the puck for straight track applications that use standard MagneMover LITE
motors. Contact your Motion Solutions Consultant or Technical Support (see
mation Support on page
The maximum load that is indicated in
material being carried.
NOTE: Off-centered (cantilevered) loads and/or large inertia loads can affect system perfor-
mance depending on the configuration of the system.
124
486) for design guidelines for applications using curves or switches.
Table 3-4
Figure 3-50: Puck Carrier Overhang
Table 3-4: Single Glide Puck Carrier Overhang Limits
Overhang Length (mm)
<10
10
20
30
40
50
60
70
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
includes the weight of the carrier and the
Overhang Length
Maximum Load (g)
1000
964
750
614
519
450
397
355
Rockwell Auto-
Load
Carrier
MagneMotion
