Stand Assembly
700-1666-XX
182.1
Weight: 1.1 kg [2.5 lb]
Figure 4-52: Standard Precision Locator Stand Mechanical Drawing
Exposed Materials
•
6061-T6 Aluminum, Anodized per MIL-A8625-F, Type II, Class 1, Non-dyed.
®
•
Tivar
H.O.T.
•
18-8 (A2) Stainless Steel.
•
316 Stainless Steel.
MagneMover LITE User Manual
112.0
96.0
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Specifications and Site Requirements
Mechanical Specifications
159.8
All Dimensions in Millimeters [inches]
