Specifications and Site Requirements
Mechanical Specifications

Spine Plates

Spine plates are preassembled onto the support post assemblies that are used by the precision
rail system as shown in
Exposed Materials
• Aluminum MIC-6
700-1622-00
6X R4
125.0°
Left
700-1622-03
Right
Figure 4-45: Precision Rail Straight to Curve, Spine Plates, Mechanical Drawing
194
Figure 4-44.
®
.
141.5°
128.5°
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
0
2X 54.98
64.98
94.99
114.98
R169.88
138.90
150.0
[0.25]
6.35
All Dimensions in Millimeters
